Coffret de protection compact AC/DC, ssPF DC, pour onduleurs monophasés SolarEdge SE5000H/SE6000H -

The compact AC/DC ssPFDC protection box, part number SW3569-32A, is designed to effectively protect single-phase photovoltaic systems with mid-power inverters. It is particularly suited to photovoltaic installers working on residential or small commercial systems equipped with SolarEdge SE5000H or SE6000H inverters. Thanks to its dedicated configuration, this box centralizes AC and DC protection in a single, optimized enclosure. This AC/DC box includes an AC section sized for a 230V AC single-phase supply with a 32A protection rating, corresponding to the typical power outputs of SolarEdge SE5000H/SE6000H inverters. On the DC side, it features a disconnect switch (or disconnect-switch) suitable for the DC voltage from photovoltaic strings (typically up to 600V to 1000V depending on the configuration) and a Category II DC surge protector to ensure overvoltage protection on the panel side. Thanks to its compact, pre-wired design, it allows for simplified connection of the panel inputs and inverter output. The enclosure also complies with applicable solar installation standards (e.g., NF C15-712-1 or equivalent) and incorporates components certified for photovoltaic use. By adopting this compact AC/DC enclosure, installers benefit from significant time savings during installation: pre-configuration reduces on-site interventions and component management is simplified. Dual AC/DC protection not only ensures the safety of the installation (differential detection, disconnection, surge protection), but also protects the investor by limiting the risks of damage and reduced performance due to overvoltages or faults. Direct compatibility with SolarEdge SE5000H/SE6000H single-phase inverters optimizes the product-installation match: this enclosure represents added value compared to a generic enclosure by being calibrated for this power range, thus reducing oversizing costs and improving integration into photovoltaic systems. In a residential setting, for example, for a 5 to 6 kWp self-consumption installation equipped with a SolarEdge SE5000H inverter, this SW3569-32A enclosure is perfectly suited: it is mounted between the panels and the inverter, on the wall of the technical shelter or in the garage, offering consistent protection and simplified wiring. For a small commercial installation or a photovoltaic carport up to approximately 6kW single-phase, its 32A disconnect switch and dedicated enclosure guarantee a reliable and compliant solution without the need for a bulkier three-phase control box. Finally, compared to control box versions designed for lower or higher power outputs, this model stands out with its "intermediate" format, specifically optimized for this power range, reducing size, materials, and costs without compromising safety or compliance.
