AC protection box for Solis S6-EH3P12K-H three-phase hybrid inverters -

This enclosure is designed to secure high-power, three-phase photovoltaic installations, particularly those equipped with inverters such as the 90kW to 100kW range. It provides a reliable interface between the inverters and the AC grid, offering complete AC power protection. The TGBTACSW2129S is rated for a nominal voltage of 400Vac three-phase. It is equipped with a 160A disconnect switch, a Schneider Electric "C160A" circuit breaker, and integrates a Type 2 AC surge protector for protection against induced or atmospheric overvoltages. Its flush-mounted design with an IP54 polyester enclosure ensures good resistance to outdoor or industrial environments. An external side handle allows for quick and safe disconnection for maintenance or in case of emergency. By integrating this control box, installers offer their clients optimal protection for both the inverter and the AC grid, while simplifying integration thanks to a pre-wired, multi-brand compatible solution. The robust components and compliance with standards enhance the system's reliability, reduce maintenance, and extend equipment lifespan. The side handle improves ergonomics, especially for quick interventions. This control box is designed for professional photovoltaic installations (high-end residential, commercial, or industrial) using a three-phase inverter from 80kW to 100kW. It is suitable for sites where AC protection is a key element for system reliability and grid compliance. The TGBTACSW2129S is a turnkey solution for AC protection of demanding photovoltaic systems: it combines compatibility, performance, and reliability, simplifying installation while ensuring enhanced equipment safety.
